Product Overview
FEATURESSPECIFICATIONS & PACKING INFORMATIONMAKE OF ITWHATYOUWILLCooler Master is breaking new ground in the way cases are designed, made, bought and used. Fundamental to this reimagining is FreeForm?.We want you to have absolute control over how your case looks and functions, and that means giving you the option to adjust the exterior structure and aesthetic via a range of replacement panels and doors. Each choice changes the look and feel of the case, but also the flexibility of the interior layout.
Technical Specifications
Product Name
MasterCase MC500 Available Color
Dark metallic grey exterior with black interior Materials
Steel, Plastic, tempered glass Motherboard
E-ATX (up to 12" x 10.7"), ATX, Micro-ATX, Mini-ITX Expansion Slots
7 Drive Bays
5.25": 2
Combo 2.5"/3.5": 2
SSD: 2 Drive Bays support
5.25": 2
Combo: 2.5"/3.5" 8 or 10 (with ODD bay removed)
SSD: 4 I/O Port
USB 3.0 x 2, USB 2.0 x 2, Audio in / out (supports HD Audio) Pre-installed Fan(s)
Front: 140mm x 1 (1200RPM)
Rear: 140mm x 1 (1200RPM) Fan Support
Front: 120 / 140mm x 3
Top: 120mm x 2
Rear: 120 / 140mm x 1 Radiator Support
Front: 120 / 140 / 240 / 280 / 360mm
Rear: 120 / 140mm
Top: 120 / 240mm Clearances
VGA: 412mm (without 3.5" HDD cage)
296mm (with 3.5" HDD cage)
CPU: 190mm Cable Routing
Behind MB Tray: 25mm - 35mm Dust Filters
Top, Front, Bottom Power Supply Support
Bottom Mount, ATX Item Dimension ( L inch x W inch x H inch)
24 x 14 x 26 Weight
53.00 lb Warranty Information
3 Years
