Supermicro MBD-X10DRW-E-O MBD-X10DRW-E - PROPRIETARY - INTEL XEON PROCESSOR E5-2600 V4/ V3 FAMILY - INTEL

Form Factor
Proprietary WIO, 12.3" x 13" (31.2cm x 33.0cm) Processor/Cache
CPU:
- Intel Xeon processor E5-2600 v4/v3 family (up to 145W TDP)
- Dual Socket R3 (LGA 2011)
Cores / Cache: Up to 22 Cores / Up to 55MB Cache
System Bus: QPI up to 9.6 GT/s System Memory
Memory Capacity:
- 16x 288-pin DDR4 DIMM slots
- Up to 2TBECC 3DS LRDIMM, 512GB ECC RDIMM
Memory Type: 2400/2133/1866/1600MHz ECC DDR4 SDRAM 72-bit
DIMM Sizes:
- RDIMM: 32GB, 16GB, 8GB, 4GB
- LRDIMM: 64GB, 32GB
- 3DS LRDIMM: 128GB
Memory Voltage: 1.2 V
Error Detection: Corrects single-bit errors On-Board Devices
Chipset: Intel C612 chipset
AHCI SATA: SATA3 (6Gbps) RAID 0, 1, 5, 10
SCU SATA: SATA3 (6Gbps) RAID 0, 1, 5, 10
IPMI:
- Support for Intelligent Platform Management Interface v.2.0
- IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
- ASPEED AST2400 BMC
Network Controllers:
- Intel i350-AM2 Dual Port Gigabit Ethernet Controller
- Virtual Machine Device Queues reduce I/O overhead
- Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
- 1x Realtek RTL8211E PHY (dedicated IPMI)
Video: ASPEED AST2400 BMC Input / Output
SATA: 10x SATA3 (6Gbps) ports
LAN:
- 2x RJ45 Gigabit Ethernet LAN ports
- 1x RJ45 Dedicated IPMI LAN port
USB:
- 2x USB 3.0 ports (via header)
- 4x USB 2.0 ports (rear)
Video: 1x VGA port
Serial Port / Header: 1x Header
DOM: 2x SuperDOM (Disk on Module) ports
TPM: 1x TPM Header Chassis (Optimized for X10DRW-E )
1U Chassis:
- SC116TQ-R700WB
- SC113TQ-R700WB
- SC815TQ-600WB
- SC113TQ-600WB
- SC815TQ-R706WB
- SC514-R400W
2U Chassis:
- SC825TQ-R740WB
- SC826BA-R920WB
- SC213A-R740WB
- SC826BAC4-R920WB
- SC216BA-R920WB
Important Chassis Notes: To support the new generation Intel Xeon processor-based motherboards, Revision M chassis is recommended. Please talk to your sales representative for details. SuperServer(s) with X10DRW-E
Model(s): SYS-1028R-WMR Expansion Slots
PCI-Express: Riser card support: Left side - 1 PCI-E 3.0 x32 System BIOS
BIOS Type: 128Mb SPI Flash EEPROM with AMI BIOS
BIOS Features:
- Plug and Play (PnP)
- PCI 2.3
- ACPI 1.0 / 2.0 / 3.0 / 4.0
- USB Keyboard support
- SMBIOS 2.7.1
- UEFI 2.3.1 Management
Software:
- SuperDoctor 5
- Intel Node Manager 3.0
- Watch Dog
- NMI
- IPMI 1.5 / 2.0
Power Configurations:
- ACPI Power Management
- Power-on mode for AC power recovery PC Health Monitoring
Voltage:
- Monitors for CPU Cores, +1.8V, +3.3V, +5V, +12V, +3.3V Standby, +5V Standby, VBAT, Memory Voltages.
- 6 Phase-switching voltage regulator
FAN:
- 6x 4-pin fan headers (up to 6 fans)
- 6x fans with tachometer monitoring
- Status monitor for speed control
- Pulse Width Modulated (PWM) fan connectors
Temperature:
- Monitoring for CPU and chassis environment
- CPU thermal trip support
- Thermal Control for 6x Fan Connectors
- Thermal Monitor 2 (TM2) support
- PECI
LED:
- CPU / System Overheat LED
- Suspend static indicator LED
- UID/Remote UID
Other Features:
- Chassis intrusion detection
- Chassis intrusion header
- SDDC Support
- RoHS Operating Environment
Operating Temperature Range: 10^oC - 35^oC (50^oF - 95^oF)
Non-Operating Temperature Range: -40^oC - 70^oC (-40^oF - 158^oF)
Operating Relative Humidity Range: 8% - 90% (non-condensing)
Non-Operating Relative Humidity Range: 5% - 95% (non-condensing) Item Dimension (L inchxW inchxH inch)
NA

Weight
5.00 lb

Warranty Information
1 Year
