Technical Specifications
16 external 6 Gb/s SAS+SATA ports
8 lanes, PCI Express 3.0
Low profile form factor design
Four x4 external - mini-SAS HD connectors (SFF8644)
Two LSI SAS 2308 6Gb/s SAS+SATA Controllers
Supports up to 1024 SAS or SATA end devices
Supports SSDs, HDDs and tape drives
Maximum connectivity and performance in a low profile form factor
8 lanes of PCI Express 3.0 provides faster signaling for high-bandwidth applications
High performance with 6Gb/s data transfer rates
IO Controller
Two, LSISAS2308/ Fusion MPT 2.0
Storage Connectivity Data Transfer Rates
16 ports 6Gb/s SAS 2.1 compliant
SAS Bandwidth
Half Duplex
2400MB/s, x4, 6Gb/s SAS lanes
Port Configurations
16 ea, x1 ports (individual drives)
4 ea, x4 wide ports
2ea , x8 wide ports
Host Bus
x8 lane, PCI Express 3.0 compliant
PCI Data Burst Transfer Rates
Half Duplex
8000MB/s, x8, PCIe 3.0
Connectors
Four (x4) mini-SAS HD external connector(SFF8644)
Brackets
Full height and low profile
Cable Support
Passive Copper, Active Copper, Active Optical
Operating Voltage
+12V +/-8% 3.3V +/-9%
PCI Power (Nominal)
33.7W
Device Support
1024-SAS/SATA devices
MTBF
>1,300,000 hours
Regulatory Certifications
EMC: Class B-US (CFR 47, P15B) Canada (ICES-003) Japan (V-3/02.04) Europe (EN55022/EN55024) Australia/New Zealand (AS/NZS 3548) Korea (N-B 2-0001-404) Safety: EN60950 RoHS WEEE
OS Support
Microsoft Windows, Linux (SuSE , Red Hat), Solaris, VMware , FreeBSD
Item Dimension (L"xW"xH"):
6 x 10.25 x 1.625
Weight:
1.5 lb
Warranty Information:
3 Years
