Technical Specifications
MB Form Factor
Mini-ITX Case Size
8.2L
S.F.F Slim Chassis
(Ultra Small Form Factor) Color
Black/White External Drive Bays
5.25 x 1 Internal Drive Bays
3.5" HDD (1") x 1
3.5" HDD (0.8") x 1 Front Ports
USB 3.0 x 2,
HD Audio Product Dimensions (H x W x D) with Front Panel
268 x 103 x 355 mm (10.6" x 4.1" x 14") Product Dimensions (H x W x D) w/o Front Panel
265 x 100 x 310 mm (8.2L)
10.4"x 3.9" x 12.2" I/O Expansion Slots
Low Profile Card Slot x 1 Model
BP655 Power Supply
Standard TFX 12V Thermal Solution
80x80x25mm Top Fan Safety
Meets RoHS, CE and FCC Class B Requirements Security
Padlock Loop / Kensington Slot Optional
IEEE 1394
eSATA / USB2.0 x 2 (at Rear Panel w/ Module)
Removable Air Filter
Chassis Intrusion Switch
Screw-less ODD Bay Clips
Screw-less Side Panel Clips
USB 2.0 x 2
3.5 to 2.5 HDD/SSD Bracket Item Dimension (L inchxW inchxH inch)
14 x 6 x 17
Weight
9.00lb
Warranty Information
1 year
