Tyan B7108T200X4-220PV3HR System B7108T200X4-220PV3HR 2U RM Dual Socket Xeon 3x3.5 inch HotSwap pre blade HDD Retail

System
Form Factor: 2U Rackmount
Chassis Model: TN200
Motherboard Name: (4) S7108GMR (4 blades in one chassis)
Board Dimension: 6.79" x 20.26" (172.4 x 514.7mm)
Blade Dimension (D x W x H): 20.66" x 7.06" x 1.6" (524.8 x 179.3 x 40.7mm)
Feature: Four blades in one chassis Front Panel
Buttons: (4) ID w/ LED / (4) PWR w/ LED
I/O Ports: (4) Display ports (2 x USB2.0 + 1 x D-SUB VGA ports w/ via cable, per port ) External Drive Bay (per blade)
Qty / Type: (3) 3.5" Hot-Swap HDD Bays, Total (12) devices
HDD backplane support: (12) SAS 12Gb/s / SATA 6.0Gb/s
Supported HDD Interface: SATA 6Gb/s System Cooling Configuration (per blade)
FAN: (4) 8cm fans Processor (per blade)
Qty / Socket Type: (2) LGA3647
Supported CPU Series: Intel Xeon Processor Scalable Families
Thermal Design Power (TDP) wattage: Max up to 165W
System Bus: Up to 10.4/9.6 GT/s with Intel UltraPath Interconnect (UPI) support
Notification: 165W CPUs are supported with certain system configurations. Please contact Tyan Technical Support for additional information. Chipset (per blade)
PCH: Intel C621 Memory (per blade)
Supported DIMM Qty: (8)+(8) DIMM slots
DIMM Type / Speed: Up to 512GB RDIMM/ 1,024GB LRDIMM/ 2,048GB LRDIMM 3DS Follow latest Intel DDR4 Memory POR
Memory channel: 6 Channels per CPU
Memory voltage: 1.2V Expansion Slots (per blade)
PCI-E: (1) PCI-E Gen3 x16 slot (Half-height, Half-length) / (1) PCI-E Gen3 x8 slot (Half-height, Half-length) / (1) PCI-E Gen3 x16 OCP 2.0 slot (conn.A+conn.B+conn.C)
Pre-install TYAN Riser Card: (1) M7108T200-L16-1L riser card for (1) PCI-E Gen3 x16 slot / (1) M7108T200-R8-1L riser card for (1) PCI-E Gen3 x8 slot LAN (per blade)
Qty / Port: (1) PHY
PHY: Realtek RTL8211E Storage (per blade)
sSATA
Connector: (2) 8-pin SATA DOM
Controller: Intel C621
Speed: 6.0 Gb/s
RAID: RAID 0/1/10/5 (Intel RSTe)
M.2 connector: (2) M.2 connector (22110/2280) by PCI-E interface Graphic (per blade)
Connector type: D-Sub 15-pin
Resolution: Up to 1920x1200
Chipset: Aspeed AST2500 I/O ports (per blade)
USB: (2) USB3.0 (at rear)
COM: (1) DB-9 COM port
VGA: (4) Display ports (2 x USB2.0 + 1 x D-SUB VGA ports w/ via cable, per port, at front )
RJ-45: (1) GbE port dedicated for IPMI TPM (per blade)
TPM Support: Please refer to our TPM supported list. System Monitoring (per blade)
Chipset: Onboard Aspeed AST2500
Temperature: Monitors temperature for CPU and memory and system environment
Voltage: Monitors voltage for CPU, memory, chipset and power supply
LED: Over temperature warning indicator, Fan and PSU fail LED indicator
Others: Watchdog timer support Server Management (per blade)
AST2500 IPMI Feature: 24-bit high quality video compression, 10/100/1000 Mb/s MAC interface
AST2500 iKVM Feature: IPMI 2.0 compliant baseboard management controller (BMC), Supports storage over IP and remote platform-flash, USB 2.0 virtual hub
Onboard Chipset: Onboard Aspeed AST2500 BIOS (per blade)
Brand / ROM size: AMI / 32MB
Feature: Hardware Monitor / SMBIOS 3.0/PnP/Wake on LAN / Boot from USB device/PXE via LAN/Storage / User Configurable FAN PWM Duty Cycle / Console Redirection / ACPI sleeping states S4,S5 / ACPI 6.1 Power Supply
Type: RPSU
Input Range: AC 200-240V/13A
Output Watts: 2,200 Watts
Efficiency: PFC / 80 plus Platinum
Redundancy: 1+1 Operating System
OS supported list: Please refer to our AVL support lists. Regulation
FCC (DoC): Class A
CE (DoC): Class A
CB/LVD: Yes
RCM: Class A
VCCI: Class A Operating Environment
Operating Temp.: 10^o C - 35^o C (50^o F- 95^o F)
Non-operating Temp.: - 40^o C - 70^o C (-40^o F - 158^o F)
In/Non-operating Humidity: 90%, non-condensing at 35^o C
