Technical Specifications
Output
Nominal Output Voltage:120V
Maximum Total Current Draw:16
Output Connections:(8) NEMA 5-20R (Battery Backup)
Input
Nominal Input Voltage:100V , 120V
Input frequency:50/60 Hz
Input Connections:NEMA L5-20P
Cord Length:12ft ( 3.66meters )
Acceptable Input Voltage:100-120VAC
Number of Power Cords:1
Load Capacity:2400VA
Maximum Input Current:20A
Regulatory Derated Input Current (North America):16A
Physical
Rack Height:1U
Color:Black
Environmental
Operating Temperature:32 - 113 oF ( 0 - 45 oC )
Operating Relative Humidity:0 - 95 %
Operating Elevation:0-10000ft ( 0-3000meters )
Storage Temperature:-25 - 65 oC
Storage Relative Humidity:0 - 95 %
Storage Elevation:0-50000ft ( 0-15000meters )
Conformance
Approvals:cUL Listed, CSA, FCC Part 15 Class A, ICES-003, Industry Canada, UL 60950, UL Listed
Sustainable Offer Status
RoHS:Compliant
REACH:REACH: Contains No SVHCs
Battery Directive:Compliant
Battery Notes:ts_Battery_Notes
Item Dimension (L inchxW inchxH inch)
14 x 3 x 19 Weight
7.60lb Warranty Information
2 years repair or replace
